2/4 Schneiden quadratische Schaftfräser

Our 2/4 Flutes Square End Mills are expertly crafted to deliver superior performance and precision in a wide range of milling applications. These versatile tools are ideal for achieving excellent surface finishes, efficient material removal, and reliable cutting performance.

Vorteile:

  1. Vielseitigkeit: Available in both 2-flute and 4-flute designs, these end mills cater to various machining needs:
    • 2-Flöte: Ideal for effective chip evacuation, especially in softer materials. This design reduces the risk of clogging and allows for smoother cutting action.
    • 4-Flöte: Provides a finer surface finish and is suitable for harder materials, offering increased stability and precision during cutting.
  2. Hohe Präzision: Our end mills are engineered with precise geometry to ensure accurate material removal and a high-quality finish. This precision reduces deviations and ensures consistent performance in demanding applications.
  3. Hervorragende Oberflächenbeschaffenheit: The optimized design of the cutting edges and flute geometry ensures an excellent surface finish, reducing the need for secondary finishing operations and improving overall productivity.

Produktdetails

Produktnummer
Artikelnummer
Klingendurchmesser
(D)
Schaftdurchmesser
(D)
Inclination
(α°)
Large end diameter
(BD)
Klingenlänge
(Ap1 max)
Volle Länge
(Mitte)
H-04D0030T005 3.0 4 0.5° 3.17 10 50
H-04D0030T010 3.0 4 1.0° 3.35 10 50
H-04D0030T015 3.0 4 1.5° 3.52 10 50
H-04D0030T020 3.0 4 2.0° 3.07 10 50
H-04D0030T030 3.0 6 3.0° 4.05 10 50
H-04D0030T040 3.0 6 4.0° 4.05 10 50
H-04D0030T050 3.0 6 5.0° 4.75 10 50
H-06D0040T005 4.0 6 0.5° 4.26 15 50
H-06D0040T010 4.0 6 1.0° 4.52 15 50
H-06D0040T015 4.0 6 1.5° 4.79 15 50
H-06D0040T020 4.0 6 2.0° 5.05 15 50
H-06D0040T030 4.0 6 3.0° 5.57 15 50
H-08D0040T040 4.0 8 4.0° 5.57 15 60
H-08D0040T050 4.0 8 5.0° 6.62 15 60
H-06D0050T005 5.0 6 0.5° 5.35 20 60
H-06D0050T010 5.0 6 1.0° 5.70 20 60
H-08D0050T015 5.0 8 1.5° 6.05 20 60
H-08D0050T020 5.0 8 2.0° 6.40 20 60
H-08D0050T030 5.0 8 3.0° 7.10 20 60
H-10D0050T040 5.0 10 4.0° 7.10 20 60
H-10D0050T050 5.0 10 5.0° 8.50 20 60
H-08D0060T005 6.0 8 0.5° 6.35 20 60
H-08D0060T010 6.0 8 1.0° 6.70 20 60
H-08D0060T015 6.0 8 1.5° 7.05 20 60
H-08D0060T020 6.0 8 2.0° 7.40 20 60
H-10D0060T030 6.0 10 3.0° 8.10 20 75
H-10D0060T040 6.0 10 4.0° 8.10 20 75
H-10D0060T050 6.0 10 5.0° 9.50 20 75
H-10D0080T005 8.0 10 0.5° 8.44 25 75
H-10D0080T010 8.0 10 1.0° 8.87 25 75
H-10D0080T015 8.0 10 1.5° 9.31 25 75
H-10D0080T020 8.0 10 2.0° 9.75 25 75
H-12D0080T030 8.0 12 3.0° 10.62 25 75
H-12D0080T040 8.0 12 4.0° 10.62 25 75
H-12D0080T050 8.0 12 5.0° 12.37 25 75
H-12D0100T005 10.0 12 0.5° 10.61 25 100
H-12D0100T010 10.0 12 1.0° 11.22 35 100
H-12D0100T015 10.0 12 1.5° 11.83 35 100
H-12D0100T020 10.0 12 2.0° 12.44 35 100
H-12D0100T030 10.0 12 3.0° 13.67 35 100
H-16D0100T040 10.0 16 4.0° 13.67 35 100
H-16D0100T050 10.0 16 5.0° 16.00 34.2 100
